Product Features
Key design and engineering features of the 10KG
✓
10kg rated thrust force for medium-duty linear positioning and actuation
✓
Precise linear motion through robust integrated motor-gearbox-leadscrew assembly
✓
Higher thrust capacity than 5kg model for heavier industrial positioning loads
✓
Reliable 24/7 continuous duty rating for industrial automation applications
✓
Self-locking leadscrew geometry for passive position hold when power is removed
✓
Standard mounting interface for straightforward installation
Technical Specifications
Full parameter data and dimensional drawings
📋 Performance Parameter Table
📐 Dimensional Drawing
| Parameter | Specification |
|---|
| Model | 10KG |
| Type | Linear Actuator |
| Power | See details |
| Voltage | See details |
| Speed | See details |
| Gear Ratio | See details |
| Shaft | See details |
| Frame | See details |
| Duty Cycle | S1 — Continuous 24/7 |
| Certification | ISO 9001 · CMA · CNAS · ILAC-MRA |
Applications
Typical industries and equipment where the 10KG excels
🏗️
Industrial Machinery Positioning
Heavy panel tilting, press tool positioning and machine adjustment mechanisms.
♿
Accessibility Equipment
Wheelchair ramp drives, stairlift actuators and accessible facility automation systems.
🚜
Agricultural Machinery
Heavy-duty implement positioning, cab adjustment and equipment control actuators.
🏭
Production Line Control
Fixture clamping, workpiece positioning and automated tooling adjustment systems.
Advantages
Why engineers and buyers choose CoreMotor Tech
01
10kg thrust handles positioning loads beyond the capacity of smaller actuators
02
Integrated design eliminates need for separate motor, gearbox and leadscrew components
03
ISO 9001, CMA, CNAS, ILAC-MRA certified — complete export documentation standard
04
OEM available from MOQ 50 units with custom stroke, voltage and speed specifications
Frequently Asked Questions
Common questions about the 10KG
When should I choose the 10kg over the 5kg actuator?+
Choose the 10kg when your load calculation shows the 5kg model would operate above 80% of its rated thrust in continuous duty, or when peak loads exceed the 5kg rating. The 10kg provides a comfortable safety margin for medium-duty applications.
What stroke lengths are available?+
Multiple stroke lengths are available. Please contact us with your required stroke and we will confirm available options and lead times.
Can the actuator be controlled by a PLC?+
Yes. With an appropriate motor driver or relay circuit, the actuator can be controlled by PLC digital outputs for extend, retract and stop commands. Contact us for wiring guidance.
Is a limit switch included?+
Limit switches are available as an option to prevent over-travel at end of stroke. Please specify this requirement when requesting a quotation.
